Yamaha DXR12 mk3 Powered Loudspeaker
The Yamaha DXR12 mk3 powered loudspeaker is built for clear, controlled sound in a format that’s easy to move and set up. With a 12-inch LF driver, 1.75-inch HF driver, and 134 dB SPL output, it suits front-of-house, monitor, and side-fill use. It also adds DSP flexibility and Bluetooth® support for modern live setups.
Made for flexible live sound
The DXR12 mk3 fits into all kinds of rigs, from DJ nights to live bands and speech reinforcement. Its FOH/Main, Monitor, DJ, Live Music, Speech, and Off DSP modes make it simple to match the speaker to the job. As a result, you spend less time adjusting and more time focusing on the performance.
Yamaha DXR12 mk3 powered loudspeaker control
Built-in D-Remote app support lets you manage the speaker from an iOS or Android device, which is handy when you want quick changes without going back to the box. Bluetooth® streaming adds extra convenience, while the intelligent feedback suppressor helps keep things clean and usable in real rooms.
Clear sound with solid low-end response
FIR-Xâ„¢ tuning and Drive Motion Calibrationâ„¢ work together to help keep the sound balanced and consistent. The 12-inch LF and 1.75-inch HF drivers, plus the large-diameter horn and optimised port positioning, are all there to support clear projection and controlled coverage across the room.
Built for practical setups
The lightweight polypropylene enclosure, side handles, dual 35 mm pole sockets, and rigging points make the DXR12 mk3 easy to place in different venues. It can be used vertically or horizontally with the optional U-bracket, and the monitor angle gives you another option for stage use.
Key Features
- 2-way, bi-amped powered speaker, bass-reflex design
- 12″ LF + 1.75″ HF proprietary high-durability speaker units
- 2000W Class-D amplifier
- 134 dB SPL maximum output
- DSP modes for FOH/Main, Monitor, DJ, Live Music, Speech, and Off
- Bluetooth® Version 5.0 with A2DP (SBC, AAC), Class 1
- Yamaha D-Remote app control for iOS and Android
- Dual 35 mm pole sockets with 0° and -7° tilt
- Monitor Angle: 52°
- Weight: 17.4 kg
