Vonyx CCD20 Compression Coaxial Speaker Driver – 8-Inch
The Vonyx CCD20 compression coaxial speaker driver brings clear music and speech reproduction to pro audio installations where enclosure space matters. Its coaxial assembly combines an 8-inch woofer with a centrally positioned compression horn driver. Meanwhile, the slim profile makes it easier to plan compact enclosures.
Clearer Music and Speech
The CCD20 works as both a reliable replacement speaker driver and a full range driver. As a result, it suits installations that need one driver to cover music and speech reproduction. Its integrated horn compression and CCAW voice coil technology focus on midrange clarity. This gives spoken content and musical detail a clear place in the mix.
Power for Installation Work
This driver delivers a maximum 1200W power output and a 600W RMS rating, so it handles substantial pro audio applications. Its 8-inch woofer and high compression driver also work together in one coaxial assembly, keeping the key driver elements together for a practical full-range speaker design.
Built for Compact Enclosures
The slim design suits compact enclosure installations, making the driver a practical choice when space is limited. In addition, a die-cast aluminium frame reduces unwanted resonance. The black finish and compact Ø210 x 133mm dimensions keep the physical design simple for installation planning.
Key Features
- Combines an 8-inch woofer and high compression driver for music and speech reproduction
- Offers a 600W RMS rating and maximum 1200W power output
- Uses a die-cast aluminium frame to reduce unwanted resonance
- Slim construction suits compact enclosure installations
