RCF EVOX 12 Active Two-Way Array – 1400W
RCF EVOX 12 is the most powerful line source in its class. It offers a particularly profound and dynamic reproduction at high levels due to the built-in 1400W power amplifier. The top section has eight high-performance neodymium 4 “full-range transducers with a phase plug. As a result, the EVOX 12 has a significantly increased low-mid playback at a constant level. Specifically, with a wide dispersion for the highs.
The 15” subwoofer delivers a powerful bass sound to reinforce a big party or live kick drum. Despite high performance, the enclosure is very compact, and thanks to integrated wheels and an extendable handle, it’s very easy to transport.
Key Highlights:
- 1400 Watt
- 15″ Woofer
- 8 x 4″ neodymium full-range woofer
- 130 dB max SPL
ACOUSTICAL SPECIFICATIONS
Frequency Response: 40 Hz ÷ 20000 Hz
Max SPL @ 1m: 130 dB
Horizontal Coverage Angle: 90°
Vertical Coverage Angle: 30°
TRANSDUCERS
Fullrange: 8 x 4.0”, 1.0” v.c
Woofer: 15”, 3.0” v.c
INPUT/OUTPUT SECTION
Input Signal: bal/unbal
Input Connectors: XLR, Jack
Output Connectors: XLR
Input Sensitivity: -2 dBu/+4 dBu
PROCESSOR SECTION
Crossover Frequencies: 180 Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Volume, EQ
POWER SECTION
Total Power: 1400 W Peak, 700 W RMS
High Frequencies: 400 W Peak, 200 W RMS
Low Frequencies: 1000 W Peak, 500 W RMS
Cooling: Convection
Connections: VDE
PHYSICAL SPECIFICATIONS
Cabinet/Case Material: Baltic birch plywood
Colour: Black, White – RAL 9003
SIZE
Height: 2200 mm / 86.61 inches
Width: 410 mm / 16.14 inches
Depth: 560 mm / 22.05 inches
Weight: 36.4 kg / 80.25 lbs
SHIPPING INFORMATION
Package Height: 636 mm / 25.04 inches
Package Width: 459 mm / 18.07 inches
Package Depth: 613 mm / 24.13 inches
Package Weight: 43.89 kg / 96.76 lbs
