Ortofon VNL TRIX Cartridge

The Ortofon VNL TRIX channels raw power and surgical precision into a cartridge built to rule any booth. From underground basements to big-room arenas, its explosive 10 mV output and rock-solid tracking unleash music exactly as you intend.

Raw Volume & Pristine Clarity

Firstly pumping a class-leading 10 mV, the VNL TRIX drives mixers and interfaces with headroom to spare. Quad-coil OFC windings deliver 22 dB channel separation. Therefore, ensuring every bass line, mid-range stab and high-hat cut through with unmistakable definition.

Rock-Solid Tracking for Aggressive Techniques

A spherical stylus seated on a rigid aluminium cantilever partners with Ortofon’s exclusive rubber suspension to achieve 100 µm trackability. Scratch, back-cue or slam the crossfader. VNL TRIX grips the groove and refuses to skip.

Fluorescent Visibility & Total Flexibility

The fluorescent white stylus tip glows under UV light. Thus, making target points visible even in blackout booths for faster cueing and cleaner beat-matching. Moreover, fully compatible with all VNL-series styli, the cartridge adapts instantly to any set, genre or personal preference.

Key Features

  • Explosive 10 mV output for unmatched loudness
  • 100 µm trackability resists skips during intense scratching
  • Fluorescent stylus tip enhances visibility on dark stages
  • Durable spherical stylus on aluminium cantilever
  • Interchangeable with all VNL-series styli for maximum versatility
  • Explosive 10 mV output for louder, cleaner signal on any club system
  • 100 µm trackability ensures skip-free scratching and back-cueing
  • Fluorescent white stylus glows under UV for instant visual cueing
  • Spherical stylus on rigid aluminium cantilever withstands heavy DJ use
  • Interchangeable VNL-series stylus for ultimate performance flexibility
  • Quad-coil OFC design delivers 22 dB channel separation and crystal clarity
  • Lightweight 7 g body perfectly balances modern tonearms

Output Voltage @ 1 kHz, 5 cm/s: 10 mV
Tracking Ability @ 315 Hz: 100 µm
Cantilever Material: Aluminium
Stylus Type: Spherical
Stylus Tip Radius: R 18 µm
Stylus Suspension: Ortofon exclusive rubber
Coil System: Quad coils
Coil Wire Material: OFC
Channel Separation @ 1 kHz: 22 dB
Frequency Response: 20 Hz – 20 kHz ±3 dB
Dynamic Lateral Compliance: 12 µm/mN
Recommended Tracking Force: 4.0 g
Cartridge Weight: 7 g
Body Colour: Black
Stylus Colour: Fluorescent White
Replacement Stylus: Stylus VNL TRIX
