LaserAnimation Sollinger UNREAL 120 1P65 Laser Projector
LaserAnimation Sollinger UNREAL 120 1P65 brings high-output RGB laser projection to large-scale events and permanent installations. Its IP65 housing, compact 34.5 × 28.1 × 22.3 cm footprint, integrated FB4 interface and outdoor operating range make it practical for demanding show environments and touring setups.
High-Output RGB Projection
The modular laser system combines LaserAnimation-manufactured red, green and blue RSL Gen. 4 laser diode modules. With a guaranteed optical output of 120W, 0.8 mrad divergence and a 10 mm beam specification, it delivers the core performance needed for large-scale laser displays while maintaining a compact form.
Precise Scanning and Flexible Control
Scanning reaches 38 kpps at 8°, with a maximum scan angle of 48°. Control options include the integrated FB4 interface, Stand-Alone Player and Art-Net, giving production teams practical ways to run the projector within an existing show workflow. Color selection and optional LAS LAN Disable Button configuration are handled via LA.toolbox.
Ready for Outdoor Installations
Built to IP65 standards, the housing is designed to be dust- and waterproof for outdoor use. The specified ambient temperature range of −10 °C to +40 °C suits varied conditions, while a generously dimensioned heat sink, Peltier elements for active heating and cooling, and temperature-controlled high-performance fans manage operating temperature.
Safety for Professional Show Environments
A comprehensive safety concept includes a scanfail safety circuit, physically 3-way adjustable beam blocker, key switch, interlock and emission LEDs on both the front and rear panels. These built-in controls give operators clear safety features to work with during installation and operation at events or permanent venues.
Key Features
- High-output RGB projection from modular RSL Gen. 4 laser diode modules
- Compact, lightweight housing for transport, rigging and touring applications
- IP65 construction for dust- and waterproof outdoor use
- FB4 interface, Stand-Alone Player and Art-Net control modes
- Thermal management for continuous operation
- Multiple integrated safety features, including scanfail, beam blocker, key switch and interlock
