Alto TrueMix 500 5-Channel Analog Mixer with USB

New
FREE SHIPPING
Alto TrueMix 500 5-Channel Analog Mixer with USB
Alto TrueMix 500 5-Channel Analog Mixer with USB
Alto TrueMix 500 5-Channel Analog Mixer with USB
Alto TrueMix 500 5-Channel Analog Mixer with USB
Alto TrueMix 500 5-Channel Analog Mixer with USB
Alto TrueMix 500 5-Channel Analog Mixer with USB
$149
SKU: TRUEMIX500 Category:

Build clear, flexible mixes with the Alto TrueMix 500, featuring USB audio playback and stereo recording, a mic channel with 18V phantom power, two stereo inputs, and two-band EQ in a portable format.

PID: 610

In stock

$149
Order Online for Delivery
or visit any of our 7 showrooms to purchase your items.
(Stock availabilities below)
5+ in stock
Web
Online 5+ in stock
Updating stores stocks...
Shipping Info
Seen a cheaper price elsewhere?
We'll match it!
Price Match
Price Match
Free Shipping
Free Shipping
This item comes with free shipping. Shipping fees may apply to other products.
Pay in 4 interest-free payments of $. More info
Pay /mth for 12 months interest free. Fees apply.

Alto TrueMix 500 5-Channel Analog Mixer with USB

The Alto TrueMix 500 brings straightforward analogue control and USB connectivity to home recording, livestreaming, podcasting, and performance setups. Its five analogue inputs combine with high-headroom circuitry, flexible monitoring, and clear visual controls, giving you a compact way to balance microphones, instruments, and line-level sources.

Connect the Sources You Use

The mic input combines an XLR connection, 18V phantom power, and a balanced 1/4” line input. So, Channel 1 can accommodate a dynamic mic, instrument, or other line-level signal. Moreover, two stereo input channels add balanced 1/4” TRS connections for line-level audio. Consequently, keeping the layout practical for everyday mixing.

Shape Each Channel Easily

Furthermore, every channel features a two-band EQ with colour-coded knobs. Therefore, giving you direct control over high and low frequencies as you mix. The clear layout is easy to follow in low-light situations, while gain, volume, and stereo pan controls let you make quick, focused adjustments without digging through menus.

Record and Monitor from One Mixer

USB I/O provides audio playback and stereo recording, with plug-and-play connectivity on Windows and macOS. The 2-track inputs offer assignable routing to either the Main Mix or Headphone Out, while dedicated 1/4” Main, Tape, and Headphone outputs keep monitoring and output connections close at hand.

Compact Control for Mobile Setups

Measuring 6.3″ x 7.6″ x 2.6″ and weighing 2.0 lbs., the TrueMix 500 fits neatly into portable setups. Its high-headroom circuitry is designed for minimal noise and clipping in the signal, and the included extra knob caps add a simple way to customise the control surface.

Key Features

  • Five analogue inputs for microphones, instruments, and line-level sources
  • USB playback and stereo recording for computer-based workflows
  • Two-band EQ and colour-coded controls on every channel
  • Assignable 2-track routing to the Main Mix or Headphone Out
  • Portable design for home, live, and mobile audio setups
  • USB I/O for audio playback and stereo recording
  • Mic input channel with 18V phantom power and balanced line input
  • Two stereo input channels with balanced 1/4” TRS jacks
  • Two-band EQ on all channels
  • 2-track inputs with assignable routing to Main Mix or Headphone Out
  • 1/4” Main, Tape, and Headphone outputs
  • Extra knob caps included in the box for added customization

Frequency Response: All inputs: 20 Hz – 22 kHz (±1 dB)
THD+N (Total Harmonic Distortion): All inputs: < 0.005% (@ 4 dBu, 1 kHz)
Gain Range: Mic inputs (Channel 1): 0 – 44 dB; Line input (Channel 1): 12 – 30 dBu; Line inputs (Channels 2/3): 0 dBu
Max Voltage Gain: 74 dB (Mic Input to Main Out and 2TK Output); 80 dB (Mic Input to Phones Output); 30 dB (Line Input to Main Out)
SNR (Signal-to-Noise ratio): All inputs: > 110 dBu
Impedance: Mic inputs: 3.9 kΩ; All other inputs: > 10 kΩ; 2TK output: 1 kΩ; All other outputs: 120 Ω
Crosstalk: Adjacent inputs: < -80 dB @ 1 kHz; Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, Channel 1, panned hard left or right)
Equalization: High: ±15 dB @ 12 kHz; Low: ±15 dB @ 80 Hz
Connectors: (2) 1/4” (6.35 mm) TRS outputs; (2) 1/4” (6.35 mm) TRS stereo L/R inputs; (1) 1/4″ (6.35 mm) TRS headphone output; (1) 1/4″ (6.35 mm) TRS mono input; (1) XLR input; (1) Stereo RCA L/R input; (1) Stereo RCA L/R output; (1) USB type-B input; (1) DC power input
Controls: (1) Power switch; (6) Volume control knobs (1 per input and output); (3) Gain control knobs (1 per channel); (3) EQ Hi control knobs (1 per channel); (3) EQ Low control knobs (1 per channel); (3) Stereo pan control knobs (1 per channel); (2) Locking switch buttons
Indicators: (1) Power LED; (3) Peak LEDs; (8) Main Out meter LEDs
Main Mix: Main output: (2) 1/4″ (6.35 mm) balanced TRS, +22 dBu max output; 2TK output: (2) unbalanced RCA, 0 dBu max output; Headphone output: (1) stereo 1/4″ (6.35 mm) TRS, 160 mW @ 32 Ω
Power: Connection: DC; Voltage: 18V, 500 mA; Consumption: 9 W
Dimensions (width x depth x height): 6.3″ x 7.6″ x 2.6″; 159.5 mm x 193 mm x 66 mm
Weight: 2.0 lbs.; 0.9 kg

For more information, please visit the manufacturer's website.
