Faital Pro HMF200 8 Ohm High-Frequency Driver
The Faital Pro HMF200 8 Ohm high-frequency driver delivers efficient output for professional audio applications. Its 108 dB sensitivity, paper double edge cone diaphragm and neodymium ring magnet give enclosure builders key specifications for system design.
Efficient High-Frequency Output
Firstly, with 108 dB sensitivity, the driver is designed to produce strong acoustic output from available input power. Its 40 W AES power handling and 80 W maximum power handling also make the power limits clear. Especially, when planning a suitable audio system and crossover arrangement.
Paper Diaphragm Detail
Moreover, the paper diaphragm uses a double edge cone shape, paired with a 37 mm voice coil and annular phase plug design. Together, these specified construction details are aimed at high-frequency sound reproduction. Meanwhile, the combined exit keeps the driver’s exit arrangement clearly defined for enclosure planning.
Built for Enclosure Planning
Furthermore, the 144 mm overall diameter, 77 mm depth and 102 mm 90° mounting-hole diameter give enclosure builders practical dimensions to check. A 50.8 mm throat diameter and 1.65 kg net weight add further detail when assessing the driver’s position and physical layout.
Neodymium Magnetic Design
Additionally, a neodymium ring magnet keeps the driver’s magnetic assembly compact in form. The specified flux density of 2.1 T records its magnetic performance. The 8 Ohm nominal impedance and 7 Ohm minimum impedance make the electrical characteristics clear for system design.
Key Features
- Efficient 108 dB sensitivity for high-frequency output
- Paper double edge cone diaphragm and annular phase plug design
- Neodymium ring magnet with 2.1 T specified flux density
- Defined power handling for crossover and system planning
