Faital Pro 6HX150 8 Ohm, 6-Inch Coaxial Driver/Loudspeaker
The Faital Pro 6HX150 brings low- and high-frequency sections together in one compact coaxial loudspeaker. Therefore, making it a practical choice for building two-way systems where space matters. Its separate 8 Ohm LF and HF sections, neodymium ring magnet and aluminium basket give enclosure designers a focused starting point.
Two-Way Sound in One Driver
With LF response from 90÷5000 Hz and HF response from 1500÷18000 Hz, the 6HX150 covers the key low, mid and high portions of a two-way design. The coaxial layout keeps both sections aligned in the same driver, while the HF section’s 90° dispersion angle spreads high frequencies across a broad area.
Power for Compact Builds
The LF section is rated at 150 W AES power handling, with 300 W maximum power handling, while the HF section handles 15 W AES and 30 W maximum. That combination suits enclosure projects needing a capable low-frequency section alongside a dedicated high-frequency section.
Efficient, Practical Construction
A neodymium ring magnet keeps the magnetic assembly compact, and the aluminum basket provides the driver’s rigid support structure. The 1.3 kg net weight and 95 mm depth are useful considerations when planning a speaker cabinet around limited internal space.
Designed for Enclosure Planning
Installation is easier to plan with the supplied 147 mm baffle cutout diameter, 172 mm bolt circle diameter and 186.5/162 mm overall diameter measurements. The 0.6 dm^3 net air volume filled by the loudspeaker also gives enclosure designers a specific figure to account for.
Key Features
- Combines LF and HF sections in one coaxial loudspeaker
- Separate 8 Ohm nominal impedance for LF and HF
- Broad 90° HF dispersion angle
- Neodymium ring magnet with aluminum basket
- Compact 95 mm depth for space-conscious enclosure designs
