Chamsys MediaMaster VS4+ Media Server
Chamsys MediaMaster VS4+ Media Server brings four 4K media outputs. MediaMaster Pro software and built-in mapping tools together in a rugged 4U rackmount system. It is made for visual control across television studios, streaming facilities, broadcast work, production, touring and rental environments. With network options for larger screen systems, too!
Drive Multiple 4K Outputs
Firstly, four DisplayPort media outputs give the server four dedicated 4K media connections. Meanwhile, two additional DisplayPort interface outputs support monitoring. This arrangement gives operators a clear way to manage visual content and interface screens from the same rackmount unit. Also, up to four 4K or 16 HD screens supported from one VS4+.
Shape Content for Complex Displays
Moreover, MediaMaster Pro includes LED Mapper and Video Mapper, plus Soft Edge / Geometric Correction. Together, these tools cover mapped LED and video setups where content needs to be arranged across different screen surfaces. King Net Mapper, 4096 presets and 48 playback layers add practical control for detailed visual systems.
Connect with Production Networks
Furthermore, NDI®5, Art-Net, sACN, CITP/MSEX and GDTF Personality Export are included for supported production workflows. Two 10Gb/s Ethernet outputs use cat6A, while optional SDI or HDMI inputs, DMX In/Out and Genlock allow the system configuration to be matched to the requirements of a particular installation.
Built for Rackmount Operation
The 4U chassis combines front panel control, two front USB 3.0 A Type ports and two interface screens for monitoring. A powerCON TRUE1 input accepts 110 to 240 VAC, and programmable front-panel LEDs can show different colours for status or fault finding. The result is a practical control surface for demanding production environments.
Key Features
- Four 4K media outputs for multi-screen visual systems
- MediaMaster Pro software with 48 playback layers and 4096 presets
- LED Mapper, Video Mapper and Soft Edge / Geometric Correction for mapped displays
- NDI®5, Art-Net and sACN support for networked production control
- 4U rackmount format with monitoring screens and front panel control
